FINEVINYL Marine-Grade
| Very high UV resistance |
| Designed for long-term outdoor exposure |
| Maintains clarity over time |
| Stable performance in harsh environments |
| Low shrinkage and dimensional stability |
| Excellent weldability |
Formats
- Rolls of 20, 25, 40, 50, 65 or 100m
- 16 rolls/pallet
| Min | Max | |
| Width | 200 mm | 1.4 m |
| Thickness | 0.3 mm | 1 mm |
| Length | 20 m | 100 m |
About FINEVINYL® Marine-Grade
FINEVINYL® Marine-Grade films are transparent PVC films engineered for long-term exposure to sunlight, weather, and demanding outdoor conditions. Designed for marine and exterior applications, these films maintain clarity, flexibility, and performance where standard transparent PVC materials may degrade prematurely. Finevinyl Marine-Grade films combine very high UV resistance with mechanical durability and dimensional stability, allowing light to pass through while withstanding prolonged exposure to sunlight, moisture, temperature variation, and environmental stress.
Advantages
- Very high UV resistance for long-term outdoor and marine exposure
- Maintains transparency and appearance over time
- Designed to withstand harsh weather conditions, including heat and moisture
- Stable dimensional performance to support long-life installations
- Low shrinkage for consistent fit and fabrication
- Non-sticky surface for easier processing and cleaner finished results
- Excellent weldability for efficient fabrication and joining
- Available in multiple thicknesses and roll formats to match the application
Applications
Technical Datasheet
| PROPERTIES | TEST METHOD | UNIT | STANDARD (3S) | FIRE RETARDANT | STANDARD (2S) |
| REFERENCE | - | - | REF425 | REF690 | REF436 |
| WIDTH | - | mm | 1400 | 1400 | 1400 |
| LENGTH | - | m | 20 to 65* | 20 to 65* | 20 to 65* |
| HAND | - | - | 3S | 3S | 2S |
| WEIGHT / roll | - | kg | 35 | 36 | 35 |
| WEIGHT / m² | - | gr /m² | 372 to 1240* | 390 to 1300* | 375 to 1255* |
| WEIGHT / m | - | gr /m | 520 to 1736* | 546 to 1820* | 525 to 1760* |
| FINISH | - | - | DOUBLE POLISHED | DOUBLE POLISHED | DOUBLE POLISHED |
| COLOR | - | - | CLEAR BLUE | CLEAR BLUE | CLEAR BLUE |
| UV STABILIZED | - | - | YES | YES | YES |
| FIRE RETARDANT | NF P92-507 | - | - | M2/B1 | - |
| LOW TEMP RESISTANCE (IMPACT TEST) | ASTM D746 | °C | -40 to -30* | -7 to -25* | -25 to -35* |
| TEAR RESISTANCE | ASTM D1004-13 | N | 21 to 70 (X)* 19 to 66 (Y)* | 19 to 67 (X)* 17 to 65 (Y)* | 23 to 78 (X)* 21 to 72 (Y)* |
| TENSILE STRENGTH | ISO 527-1:2012 ISO 527-3:2001 | MPa | 20 to 26 (X)* 25 to 29 (Y)* | 18 to 23 (X)* 15 to 26 (Y)* | 22 to 28 (X)* 27 to 32 (Y)* |
| ELONGATION AT BREAK | ISO 527-1:2012 ISO 527-3:2001 | % | 350 to 380 (X)* 320 to 420 (Y)* | 340 to 370 (X)* 310 to 400 (Y)* | 330 to 360 (X)* 310 to 390 (Y)* |
| HEAT SHRINKAGE (80°C, 10 min.) | DIN 53377:2007 | % | 0.7 (X) -2.2 (Y) | 0.9 (X) -2.7 (Y) | 0.5 (X) -1.9 (Y) |
The data contained in this technical specification is given for information only and is based on our current knowledge of the products concerned.
This information given to our customer in good faith to inform him and to help him in his search, does not constitute any formal or implicit guarantees as to its use.
