FINEVINYL® General-Purpose
| High transparency/clarity |
| Non-sticky surface for easy handling |
| UV-stabilized formulation |
| Flat & Low shrinkage |
| Excellent weldability |
| Environmentally friendly & recyclable |
Formats
- Rolls of 20, 25, 40, 50, 65 or 100m
- 16 rolls/pallet
| Min | Max | |
| Width | 200 mm | 1.4 m |
| Thickness | 0.3 mm | 1 mm |
| Length | 20 m | 100 m |
About FINEVINYL® General-Purpose
FINEVINYL® General-Purpose films are transparent, durable PVC films with high UV resistance for everyday and industrial applications. Finevinyl® General-Purpose films are designed for applications requiring excellent clarity, durability, and stable performance under regular use. These films offer a balanced combination of optical quality, mechanical strength, and UV resistance, making them suitable for a broad range of indoor and outdoor uses.
Advantages
- Excellent clarity and a clean, polished appearance
- Reliable durability for frequent handling and daily use
- UV resistance designed for long-term performance in light-exposed environments
- Low shrinkage to support stable fabrication and consistent fit
- Non-sticky surface for easier processing and cleaner finished results
- Good weldability for efficient fabrication and joining
Applications
Technical Datasheet
| PROPERTIES | TEST METHOD | UNIT | STANDARD (3S) | FIRE RETARDANT | STANDARD (2S) |
| REFERENCE | - | - | REF425 | REF690 | REF436 |
| WIDTH | - | mm | 1400 | 1400 | 1400 |
| LENGTH | - | m | 20 to 65* | 20 to 65* | 20 to 65* |
| HAND | - | - | 3S | 3S | 2S |
| WEIGHT / roll | - | kg | 35 | 36 | 35 |
| WEIGHT / m² | - | gr /m² | 372 to 1240* | 390 to 1300* | 375 to 1255* |
| WEIGHT / m | - | gr /m | 520 to 1736* | 546 to 1820* | 525 to 1760* |
| FINISH | - | - | DOUBLE POLISHED | DOUBLE POLISHED | DOUBLE POLISHED |
| COLOR | - | - | CLEAR BLUE | CLEAR BLUE | CLEAR BLUE |
| UV STABILIZED | - | - | YES | YES | YES |
| FIRE RETARDANT | NF P92-507 | - | - | M2/B1 | - |
| LOW TEMP RESISTANCE (IMPACT TEST) | ASTM D746 | °C | -40 to -30* | -7 to -25* | -25 to -35* |
| TEAR RESISTANCE | ASTM D1004-13 | N | 21 to 70 (X)* 19 to 66 (Y)* | 19 to 67 (X)* 17 to 65 (Y)* | 23 to 78 (X)* 21 to 72 (Y)* |
| TENSILE STRENGTH | ISO 527-1:2012 ISO 527-3:2001 | MPa | 20 to 26 (X)* 25 to 29 (Y)* | 18 to 23 (X)* 15 to 26 (Y)* | 22 to 28 (X)* 27 to 32 (Y)* |
| ELONGATION AT BREAK | ISO 527-1:2012 ISO 527-3:2001 | % | 350 to 380 (X)* 320 to 420 (Y)* | 340 to 370 (X)* 310 to 400 (Y)* | 330 to 360 (X)* 310 to 390 (Y)* |
| HEAT SHRINKAGE (80°C, 10 min.) | DIN 53377:2007 | % | 0.7 (X) -2.2 (Y) | 0.9 (X) -2.7 (Y) | 0.5 (X) -1.9 (Y) |
The data contained in this technical specification is given for information only and is based on our current knowledge of the products concerned.
This information given to our customer in good faith to inform him and to help him in his search, does not constitute any formal or implicit guarantees as to its use.
