Transparency/clarity | |
Flexibility | |
Thermal insulation | |
Noise insulation | |
Long durability | |
Impact & scratch resistance | |
Environment friendly & recyclable |
Semi-Rigid PVC is used as “Semi-Rigid Glass”. It is offering clarity, brightness and adaptable ability to be bent or rolled-up.
Semi-rigid PVC strip is most recommended to achieve flexible windows in roll up doors, rapid doors, automatic doors, semi-rigid panels for swing doors or strips doors in warm weather countries.
Properties | Standard | Units | Standard | Description |
Light transmittance | ASTM D 1003 | % | 85 | Visible light rate transmitted through the material. |
Shore A hardness | EN ISO 868 | Sh A | 85 to 95 | Index based on a flat indenter's penetration depth. Scale from 0 (Soft) to 100 (Hard). |
Tearing resistance | DIN 53515 | N/mm | 50 | Minimum tensile stress required to tear a pre-slit sample. |
Tensile strength at break | ASTM D 638 EN ISO 527 | N/mm² | 16 | Maximum tensile stress that a material can be subjected to before break. |
Elongation at break | % | 340 | Elongation of the specimen at the break point under tensile stress. | |
Residual elong. (after break) | % | 68 | Permanent elongation of the specimen measured after rupture in a tensile test. | |
Thermal conductivity | ASTM C 177 | W/m.K | 0,16 | Ability to conduct heat. The Lower it is, the more insulation. |
Cold bend brittle temp. | ISO 8570 | °C | -35 | Temperature at which the specimen break under torsion stress. Brittle point (CLASH & BERG). |
Min. usage temp. | EN 1876 | °C | -15 | Temperature range where material keep its mechanical properties (flexibility). |
Max. usage temp. | °C | +50 | ||
Specific heat capacity | ISO 11357 | kJ/kg.K | 1,6 | Heat energy required to increase the temperature of one kilogram of the material by one degree Celsius. |
Sound reduction | DIN 52210 | dB | >35 | Average sound level (freq. 0,1 to 3,2 kHz) decreased by a 1,76 sq.m. and 5 mm thick PVC curtain. |
Reaction to fire | EN 13501-1 | Class | - | Standard classifications of material self-extinguishing and resistance to combustion. |
UV/IR filter | ISO 25980 | - | - | Ability to filter welding rays allowing the use of this material as a welding protection screen. |
UV resistance | ISO4892 | - | Yes | Ability to resist to UV (Sun, welding arc). |
Surface resistivity | ASTM D257 | .1010 Ω/□ | - | Material surface electric resistivity measured with a 100 V direct voltage. |
Water absorption | EN ISO 62 | % | -0,2 | Material mass variation after exposure to humid conditions. (<0 if released / >0 if absorbed) |
Anti-insect | - | - | - | Special ability to keep insects away.(Food processing plants, tropical regions) |
Density | ASTM D 792 | g/cm3 | 1,22 | Mass per unit volume. |
